Multi-Point System Electronic Power Control - Extra Safe with ELCB
Special Features:
*Slim and compact design
*Electronic power control
*Auto flow sensor switch
*Safety pressure relief valve
*Built-in earth leakage circuit breaker (ELCB)
*Safety thermal cut-out
*Electronic power control
*Auto flow sensor switch
*Safety pressure relief valve
*Built-in earth leakage circuit breaker (ELCB)
*Safety thermal cut-out
Convenient and Economical
Just turn on the outlet control valve and the Flow Sensor Switch automatically activates the heater. The Electronic Power Control provides ideal temperature selection. When control valve is shut, the heater cuts off automatically. Thus no power wastage.
Built-in Safety System
The Pressure Relief Valve together with the Thermal Cut-Out prevent excessive pressure and temperature build up. In addition, an Earth Leakage Circuit Breaker eliminates the risk of electric shock.
Assurance of Quality
High quality materials and stringent quality control are hallmarks of our standards. Each unit is individually tested before leaving the factory in compliance to safety standards.
QC Check machine
Basic Model
Premium Model
Technical Specifications & Standards
Heater Electrical Rating Available in 3kW to 11.5kW, 220 - 240V A.C, 50/60Hz
Minimum Water Flow Rate 2 Litres/min
Maximum Water Pressure 3.87kg f/cm2 (55psi)
Water Temperature Control Electronic Control
Water Connection 15mm dia. (1/2" BSP)
Dimension 358mm(H) x 378mm(W) x 83mm(D)
Weight ( Pump Model ) 3.8 kgs
Weight ( Non Pump Model ) 2.8 kgs
* 3KW to 6KW AVAILABLE ON REQUEST.
